SC-FREQ-DIN Trumeter Frequency Signal Conditioner, 2-400 Hz, PSU: 12–24 V AC/DC, Configurable, Din Rail Mount
£91.00 plus VAT
The SC-FREQ-DIN is a DIN rail–mount, user-configurable signal conditioner with a 2–400 Hz input range for measuring DC pulses from sensors to 0.5% accuracy.
The Frequency Signal Conditioner accurately measures DC pulses from sensors across a 2–400 Hz range with 0.5% accuracy, making it ideal for industrial automation, motor control, material handling, and rotational equipment monitoring. It is designed for installation on a standard Top Hat Slotted (TS35) DIN rail and powered by 12–24 V AC/DC.Fully configurable via free software, the unit’s dual outputs are selectable as digital (open collector) or analog (4–20 mA), enabling seamless integration with control and monitoring systems. The software also allows configuration of 10 independent alarm setpoints, and additional settings for comprehensive monitoring.The Frequency Signal Conditioner is also compatible with Trumeter’s APM Gateway (sold separately) for a complete remote monitoring solution featuring free access to the Trumeter Cloud platform for real-time monitoring, data logging, alarm alerts, and API connectivity.
"• Measures DC pulses from a sensor, supporting a wide range of inputs between 2-400Hz.
• Dual outputs configurable as digital (open collector) or analog (4–20 mA)
• 10 alarm setpoints with configurable digital output delays
• 0.5% accuracy (at 25C)
• 20-point non-linearization scaling for non-linear sensors
• Standard Top Hat Slotted (TS35) DIN rail mount for simple installation
• User-configurable scaling, range, alarms, and outputs via software
• Compatible with Trumeter Cloud and APM Gateway for remote monitoring"
| Series | SC Series |
| Input Type | Hz (DC) |
| Interface | Trumeter SC Configurator Software |
| Mounting Type | TS35 DIN Rail-Mount |
| Range Input | 2 – 400Hz |
| Output Type | 2x Digital or Analog (4-20mA) |
| Type | Signal Conditioners |
| Dimensions | 2.83in × 2.41in × 1.87in (72mm x 61.2mm x 47.5mm) |
| Standards | UL, cUL, CE |
| Supply Voltage | 12-24VAC/VDC |
| Number of Outputs | 2 |
| Accuracy | 0.5% |
| Minimum Operating Temperature | 14˚F (-10˚C) |
| Maximum Operating Temperature | 140˚F (60˚C) |
| IP Rating | IP20 |
