SC-M1-DIN Trumeter M1 - Multi-function Signal Conditioner, 05 A / 0-600 V / 2-400 Hz, PSU: 12–24 V AC/DC, Configurable, Din Rail Mount
£85.00 plus VAT
The SC-M1-DIN is a 12-24V AC/DC DIN rail–mount signal conditioner, user-configurable to measure current, voltage or frequency.
The M1 Signal Conditioner is a versatile, all-in-one solution for diverse measurement needs. Use the configurator software to select measurement of current up to 5 A (or up to 10,000 A with a CT), voltage up to 600 V AC/DC, or frequency from 2–400 Hz. It is designed for installation on a standard Top Hat Slotted (TS35) DIN rail and powered by 12–24 V AC/DC.Fully configurable, via the software, the dual outputs, can be used as digital (open collector) or analog (4–20 mA), ensuring seamless integration with other systems. The software also allows configuration of 10 independent alarm setpoints for comprehensive monitoring.The M1 Signal Conditioner is also compatible with Trumeter’s APM Gateway (sold separately) for a complete remote monitoring solution featuring free access to the Trumeter Cloud platform for real-time monitoring, data logging, alarm alerts, and API connectivity.Also available for 100-240V AC PSU (SC-M2-DIN).
• 3-meters-in-1: Configurable to measure current, voltage or frequency• Dual outputs configurable as digital (open collector) or analog (4–20 mA)• 10 alarm setpoints with configurable digital output delays• Measures to 1% accuracy• True RMS measurement for accurate readings across all waveforms• Standard Top Hat Slotted (TS35) DIN rail mount for simple installation• User-configurable scaling, range, alarms, and outputs via software• Compatible with Trumeter Cloud and APM Gateway for remote monitoring.
| Series | SC Series |
| Input Type | Voltage, Current, Frequency |
| Interface | Trumeter SC Configurator Software |
| Mounting Type | TS35 DIN Rail-Mount |
| Range Input | 0 – 10,000A via CT, 0 – 5A Direct, 0 – 600V DC/AC (+/-), 2 – 400Hz |
| Output Type | 2x Digital or Analog (4-20mA) |
| Type | Signal Conditioners |
| Dimensions | 2.83in × 2.41in × 1.87in (72mm x 61.2mm x 47.5mm) |
| Standards | UL, cUL, CE |
| Supply Voltage | 12-24VAC/VDC |
| Number of Outputs | 2 |
| Accuracy | 1% |
| Minimum Operating Temperature | 14˚F (-10˚C) |
| Maximum Operating Temperature | 140˚F (60˚C) |
| IP Rating | IP20 |
